Next-generation, high-performance instrument microphone featuring CORE+ technology. This mic delivers pristine, natural and undistorted sound with exceptional isolation and off-axis rejection for any live or studio setting. Fitted with MicroLock® and a series of upgraded instrument clips, the 4099 CORE+ provides even better stability and flexibility on any type of instrument.
Since 2017, 4099 Instrument Mics have benefited from DPA’s CORE technology and now it’s time for CORE+. While CORE by DPA is a powerful technology that minimizes distortion, CORE+ offers even more, taking the 4099 to the next level.
CORE+ pushes distortion down to an absolute minimum across the entire dynamic range. Yet beyond that, CORE+ also significantly extends the dynamic range. The 1% THD threshold has been pushed 10 dB higher, meaning the microphone maintains linearity across a much wider input range. Additionally, the clipping point of the 4099 has been increased by 3 dB, allowing it to handle even more extreme sound pressure levels without compromising sound quality.
In real-life audio comparisons, CORE+ microphones stand out for their openness and natural sound, offering a clarity that surpasses other high-end microphones in their class—especially under demanding acoustic conditions.
CORE+ microphones deliver even greater clarity across the entire dynamic range, from the quietest passages to extremely high SPLs. They offer an unprecedented sense of openness. On some instruments like grand piano and horns, where the harmonic structure is essential to the instrument’s natural character, even minor artifacts can compromise the sound. With CORE+, this risk is dramatically reduced, preserving the integrity of the source. Beyond CORE+, the design and construction of the 4099 and its clip program has been completely revamped. All this, to set a new benchmark for excellence in instrument miking with the enhanced 4099 and its upgraded clip program:
- Superior Microphone Suspension
- Modernized Flocked Foam
- Special Matte Nextel™ Gooseneck Coating
- Black PVD Treatment
- Discrete Sensitivity Indicator
- G-Mount Gooseneck Mount
This microphone comes in two versions:
- CORE+ 4099 Mic, Loud SPL (red marking on gooseneck) – used to close-mike most types of instruments
- CORE+ 4099 Mic, Extreme SPL (yellow marking on gooseneck) – used to close-mike extremely loud instruments, such as drums and some brass
*The CORE+ 4099 Instrument Microphone comes with a DAD9001/DAD9099-XLR Adapter
*All DPA Microphones are condenser Microphones and require Phantom Power.
CORE+ 4099 Classic Touring Kit, 4 Mics and accessories, Loud SPL (SKU: DPA-KIT-4099-DP-4C)
This 4 x DPA CORE+ 4099 Classic Touring Kit comes with a myriad of accesories/clips for Classical Instruments. The kit consists of the following:
4 x DPA CORE+ 4099 (Loud SPL) Instrument Microphones
1 x Peli Case
4 x Violin Clips
1 x Guitar Clip
2 x Cello Clips
1 x Bass Clip
2 x Piano Clips
CORE+ 4099 Rock Touring Kit, 4 Mics and accessories, Extreme SPL (SKU: DPA-KIT-4099-DC-4R)
This 4 x DPA CORE+ 4099 Rock Touring Kit comes with a myriad of accesories/clips for Rock Instruments. The kit consists of the following:
4 x DPA CORE+ 4099 (Extreme SPL) Instrument Microphones
1 x Peli Case
3 x Drum Clips
2 x Sax Clips
2 x Universal Clips
3 x Clamp Mount Clips
CORE+ 4099 Classic Touring Kit, 10 Mics and accessories, Loud SPL (SKU: DPA-KIT-4099-DC-10C)
This 10 x DPA CORE+ 4099 Classic Touring Kit comes with a myriad of accesories/clips for Classical Instruments. The kit consists of the following:
10 x DPA CORE+ 4099 (Loud SPL) Instrument Microphones
1 x Peli Case
8 x Violin Clips
4 x Guitar Clip
2 x Cello Clips
2 x Bass Clip
2 x Piano Clips
2 x Sax Clips
2 x Universal Clips
2 x Clamp Mount Clips
1 x Stand Mount Clip
CORE+ 4099 Rock Touring Kit, 10 Mics and accessories, Extreme SPL (SKU: DPA-KIT-4099-DC-10R)
This 10 x DPA CORE+ 4099 Rock Touring Kit comes with a myriad of accesories/clips for Rock Instruments. The kit consists of the following:
10 x DPA CORE+ 4099 (Extreme SPL) Instrument Microphones
1 x Peli Case
3 x Violin Clips
2 x Guitar Clips
1 x Bass Clip
2 x Piano Clips
6 x Drum Clips
4 x Sax Clips
2 x Universal Clips
3 x Clamp Mount Clip
2 x Stand Mount Clips
THIS IS THE CORE+ VERSION OF THIS PARTICULAR DPA MICROPHONE
CORE+ is a revolutionary leap ahead in microphone design, blurring the lines between what is and isn’t acoustically possible. This technology neutralizes distortion across the entire dynamic range of the microphone making any residual distortion imperceptible to the naked ear and virtually unmeasurable.
- Effectively negates microphone distortion across the entire dynamic range
- Captures the purest, clearest sound at the source
- Lets sound engineers focus on shaping an extraordinary experience for the audience
- Reduces hassle from unpredictable challenges in the live show environment
IP58 certified
All CORE by DPA technology microphones are IP58 certified. This durability is achieved through a number of defense mechanisms:
• Water-repellant nano-coating of the cover and housing
• Hermetic sealing of the sensitive amplifier at the core of the mic
• Dual gold plating of the diaphragm
For more information on CORE+ by DPA, visit https://www.dpamicrophones.com/campaign/core-plus/
ALL MICROPHONES COME IN A MICROLOCK TERMINATION
MicroLock connections on your DPA Microphones ensures that your microphone is compatible with all professional wireless systems and bodypacks. Just purchase the right adaptor for your wireless systems and your microphone will not be rendered as a one-trick pony. for a list of DPA MicroLock adaptors, please see below:
Standard XLR - DAD9001/DAD9099
Sennheiser Evolution / G2 / G3 Series - DAD9034
Sennheiser EWDI (SKDI) - DAD9034
Sennheiser SK 50 - DAD9003
Sennheiser SK 250 - DAD9003
Sennheiser SK 2000 - DAD9003
Sennheiser SK 3063 - DAD9003
Sennheiser SK 5012 - DAD9003
Sennheiser SK 9000 - DAD9003
Shure GLXD1 - DAD9010
Shure PGX1 - DAD9010
Shure SC1 - DAD9010
Shure SLX1 - DAD9010
Shure U1 - DAD9010
Shure ULX1 - DAD9010
Shure ULDX1 - DAD9010
Shure UR1 - DAD9010
Shure UR1M - DAD9010
Shure UR1MLemo3 - DAD9003
Shure UT1 - DAD9010
Audio-Technica AEW-T1000 - DAD9033
Audio-Technica ATW-110G - DAD9033
Audio-Technica ATW-1501 - DAD9033
Audio-Technica ATW-T310 - DAD9033
Audio-Technica ATW-T701 - DAD9033
Audio-Technica ATW-T1000 - DAD9033
Audio-Technica ATW-T1001EX - DAD9033
Audio Ltd. En2 TX - DAD9034
Line 6 TB12 - DAD9010
Line 6 X2 Digital Wireless - DAD9034
Line 6 XD-V70L - DAD9010
DPA Microphones CORE+ 4099 Instrument Mic, Black, MicroLock
Directional pattern
Supercardioid
Principle of operation
Pressure gradient
Cartridge type
Pre-polarized condenser
Effective frequency response
20 Hz - 20 kHz
Frequency range, ± 2 dB, at 20 cm (7.9 in)
80 Hz - 17 kHz with 2 dB soft boost at 10-12 kHz
Sensitivity, nominal, ±3 dB at 1 kHz
Loud SPL: 6 mV/Pa; -44 dB re. 1 V/Pa
Extreme SPL: 2 mV/Pa; -54 dB re. 1 V/Pa
Equivalent noise level, A-weighted
Loud SPL: Typ. 23 dB(A) re. 20 μPa (max. 26 dB(A))
Extreme SPL: Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A))
Distortion, THD < 0.5%
Loud SPL: 135 dB SPL RMS, 138 dB SPL peak
Extreme SPL: 131 dB SPL RMS, 134 dB peak
Distortion, THD < 1%
138 dB SPL RMS, 141 dB SPL peak
Dynamic range
Loud SPL: Typ. 118 dB
Extreme SPL: Typ. Typ. 113 dB
Max. SPL, THD 10%
Loud SPL: 145 dB SPL peak
Extreme SPL: 154 dB SPL peak
Rated output impedance
From MicroLock: 30 - 40 Ω. From DAD9099 or DAD9001: 100 Ω
Cable drive capability
Up to 300 m (984 ft) with DAD9001/DAD9099 XLR Adapter
Output balance principle
Signal balanced with DAD9099 or DAD9001 XLR Adapter
Common mode rejection ratio (CMRR)
> 60 dB from 50 Hz to 15 kHz with DAD9099 or DAD9001 XLR Adapter
Power supply (for full performance)
For wireless systems Min. 5 V - max. 10 V through DPA adapterWith DAD9001 or DAD9099: P48 (Phantom Power). Will work from 12 V
Current consumption
Typ. 1.5 mA (microphone). 3.5 mA with DAD9099 or DAD9001 XLR Adapter
Connector
MicroLock
Weight
Microphone: 18 g (0.63 oz)
Microphone Clip for Accordion (A-CLIP): 5 g (0.18 oz)
Clamp Mount Microphone Clip (CM-CLIP): 16 g (0.56 oz)
Microphone Stand Clip (MS-CLIP): 24 g (0.85 oz)
Microphone Clip for Piano (P-CLIP): 20 g (0.71 oz)
Universal Microphone Clip (U-CLIP): 15 g (0.53 oz)
Instrument Microphone Clip for Guitar (GC4099): 12 g (0.42 oz)
Instrument Microphone Clip for Sax and Trumpet (STC4099): 7 g (0.25 oz)
Instrument Microphone Clip for Violin and Mandolin (VC4099): 10 g (0.35 oz)
Instrument Microphone Clip for Bass (BC4099): 20 g (0.71 oz)
Microphone Clip for Cello (C-CLIP): 18 g (0.63 oz)
Microphone diameter
5.7 mm (0.22 in)
Microphone length
50 mm (1.97 in)
Cable length
1.8 m (5.9 ft)(not included with 4099-DP-1 and 4099-DP-2)
Cable diameter
1.6 mm (0.06 in) / 2.2 mm (0.09 in)
Polarity
+V at MicroLock pin for positive sound pressure (and pin 2 on DAD9099 or DAD9001 XLR adapter)
Temperature range
-40°C to 45°C (-40°F to 113°F)
Relative humidity (RH)
Up to 90%
Gooseneck length
140 mm (5.5 in)
Sensitivity selection tolerance (at 1 kHz)
±1 dB
Color
Black
2-Year warranty by serial number. Does not cover wear and tear by analysis of DPA Microphones A/S. Two-way shipping to be borned by buyer unless product is found to be defective by manufacturing defects.
